Mg Box Structure 10 Ton Gantry Crane Price sale to Canada
$36000.00 1 1
Qingdao
L/C T/T
New
MG
CE, ISO9001
Kuangyuan
General manufacturing,Metal production industry,Renewable energy industry
Brief Introduction
| Warm tips | In order to save cost and time for you,we need your provide below information: 1.Which kinds of gantry crane do you need? 2.FOB or CIF price?(If CIF price,tell us your destination port) 3.Quantity?(set) 4.Lifting capacity?(ton) |
pecific details of double girder gantry crane
| Loading capacity | 5 ~ 800t |
| Lifting height | 3 ~ 30 m or customized |
| Lifting speed | Single speed: 1 ~ 8 m/min; or customized Variable frequency speed: 1 ~ 12 m/min; or customized |
| Span | 5~35 m |
| Lifting mechanism | Hoist trolley or Winch trolley |
| Working class | A3 ~ A7 |
| Working temperature | -20 ~ 40 ºC |
| Power supply | AC-3Phase-220//230380/400/415/440V-50/60Hz |
| Control voltage | DC-24 / 36V |
| Motor protection class | IP54 IP55 IP65 |
| Control way | Ground handle control(Push button),wireless remote control,cabnient control |
| Safety device | Buffer,current overload protection,overload device,power failure protection |
| Application area | Factory,workshop,warehouse,power station,logstic,etc. |
| Painting color | Yellow,Red or Customzied |
Technical featurers:
1) Strong box type, welding by machine hand.
2) Vacuum casting, intermediate frequency quenching
3) Wheels, wirerope drum, gears, couplings are manufactured by our CNC manchine center.
4) Heavy duty slipring motor, WUXI NGP brand (support customize).
5) Siemens main electric parts.
6) Pendent control, wireless, cabin control.
Safety features:
>Weight overload protection device,
>Polyurethane buffer,
>Travelling limit switch,
>Low voltage protection function,
>Emergency stop system,
>Current overload protection function.
Painting:
>Anti-rust painting, Primer and finishing paint, yellow or red color,
>General thickness: about 105microns
Application:
>It is one kind of heavy duty crane, it is widely used in plants, warehouses, materials stocks to lift goods or materials.
> Explosion proof type is avaliable.
Customization:
Welcome to send us email or leave me message to tell me details demand so that I can sent you offer in shortest time:
1, the lifting weight (t):
2, the lifting height (m):
3, do you need cantilever.
4, span (m):
5, duty (A*):
6, power (voltage):
7, does the jib crane is needed on the gantry crane, right side or left side?
8, lifting speed and gantry travelling speed (m/min).
9, what material would be lifted? (Deciding the lift tool and gantry type)
about us
1. We are in Crane Hometown of China, could supply you the best quality crane , grab bucket and electromagnet with high technique, and the price is the best. We have exported our product more than 100 countries.
2. We could supply you all kinds of industry cranes from 0.25tons to 900tons, pass GB/T 19001-2000 idt ISO 9001:2000, GB/T 24001-2004 idt ISO 14001:2004, GB/T 28001-2001,OHSAS 18001:1999, CE,GOST and so on.
| Capacity | t | 5, 10, 16/3.2, 20/5, 32/5, 50/10t | ||
| Span | m | 10.5~35 | ||
| Lifting height | Main hook | m | According to your requirements | |
| Aux. hook | m | According to your requirements | ||
| Operation method | Pendent control, cabin, wireless control | |||
| Speed | Lifting | Main hook | m/min | Single or VVVF, according to your requirements |
| Aux. hook | m/min | Single or VVVF, according to your requirements | ||
| Cross travel | m/min | Single or VVVF, according to your requirements | ||
| Long travel | m/min | Single or VVVF, according to your requirements | ||
| Lifting unit | type | Winch+trolley | ||
| Working duty | A5, A6, A7 | |||
| Power supply | AC | 220v/380v/400v/415v/440v, 3P | ||
Processing Facility
Packaging & Delivery
Packaging Details
Packing & Delivery terms:
1. Hoist and electric parts will be packed by plywood crate, for avoiding the demage from goods crash and impact during the delivery.
2. Girders and other main parts will be packed by plastic woven cloth, for preventing rust from soppy condition during the transportation.
3. only the best transport solution will be taken for saving your cost uttermost on finance, security and time.
Delivery Time
Shipped in 30 days after receive deposit
