Customizable LX type single beam suspension crane 10 ton Capacity

LX type single beam suspension crane product introduction:

The LX electric single-girder suspension crane is a light and small crane running on rails, used in conjunction with CD1 electric hoist and MD1 electric hoist. This machine is mostly used in machinery manufacturing, assembly workshops, warehouses and other places. The running track uses I-beam.

The LX single-girder suspension crane is an intermediate working system. The working environment temperature is between -20 and +35 degrees Celsius. The control method is ground control (wired and wireless).

This product is not suitable for working in flammable or explosive media or places with high humidity and acid or alkali gases. It is also not suitable for lifting molten metal, toxic substances and flammable substances.

Product Overview of LX Electric Single-Girder Suspension Crane

1. The LX electric single-girder suspension crane is designed and manufactured in accordance with JB/T2603-1994 standards. Its main beam structure includes I-beam main beam, box-shaped main beam and flower frame main beam structure. It has a reasonable structure and the rigidity of the whole machine. Strong characteristics.

2. The LX electric single-girder suspension crane is used together with CD1 and MD1 electric hoists. The electric hoist is suspended from the I-beam of the main beam or the lower edge of the main beam. Its lifting capacity is 0.5t-5t and its span is 3 -16m, the working level is A3-A4, and the working environment temperature is -25℃~40℃.

3. LX electric single-girder suspension crane usually adopts the operation mode of handle button + remote control.

4. LX type electric single-girder suspension crane usually uses a conical brake motor for lifting and operation, and the reduction device adopts gear reduction transmission; the whole machine is equipped with lifting and descending limit switches, cart travel switches, handle buttons, Overload limiter and other accessories.

5. The LX electric single-girder suspension crane is widely used in factories, warehouses, stockyards and other different occasions to lift goods. It is prohibited to be used in flammable, explosive and corrosive media environments.

6. The use of electric single-girder cranes with low headroom structures can effectively increase the lifting height; through reasonable design of the main beam structure and selection of suitable main beam structures, construction costs can be greatly reduced.
